Designed for studying natural sciences in schools, this laboratory kit includes a device with an LCD screen (64x128 pixels) for displaying sensor readings and configuring experiment parameters. It can store up to 100,000 measurements in its internal memory. Data transfer to a computer can be done wirelessly via Bluetooth or through a USB cable. All sensors are equipped with self-diagnostic and self-calibration functions. The device’s battery lasts up to 150 hours (assuming measurements are taken once per minute).
Specifications:
● Dimensions: 132 mm, height = 45 mm
● Weight: 300 g
● Operating temperature range: -10 to 50°C
● Measurement resolution: 12-bit
● Supported platforms: PC, Mac, iPad, Linux, Android, Chromebook
The data logger includes the following sensors:
● Water Quality pH Sensor: Range 0 to 14 pH
● Gas Pressure Sensor: Range 0 to 300 kPa
● Conductivity Sensor: Range 0 to 20 mS/cm
● Pulse Sensor: Range up to 200 beats per minute
● Temperature Sensor: Range -25 to +125°C
● Oxygen Level Sensor: Range 0 to 14 mg/L
● Electrocardiogram Sensor: Range 300 to 1100 mBar
● Colorimeter Sensor: Transmission range 10 to 90% (three colors)
● Turbidity Sensor (Nephelometer): Range 10 to 1000 NTU
● Illuminance Sensor: Range 0 to 55,000 lux
● Relative Humidity Sensor: Range 0 to 100% RH
● Thermocouple Temperature Sensor: Range +200 to +1200°C
● Ambient Temperature Sensor: Range -10 to +50°C
● Universal Port: For external sensor connection, input voltage 0 to 5V
● GPS Receiver: Simultaneous recording of longitude, latitude, direction, speed, date, and time to record research locations (accuracy within 3 meters)
Package Contents:
● Data Logger: 1 unit
● Charger: 1 unit
● USB Cable: 1 unit
● Quick Start Guide: 1 unit
● Information sheet with download link for software: 1 unit
● Plastic tube for pressure sensor: 1 unit
● Set of colorimeter cuvettes: 1 unit
● pH Electrode: 1 unit
● Conductivity Sensor Electrode: 1 unit
● Heart Rate Sensor Clip: 1 unit
